smf Vrla Batteries
PRODUCT SPECIFICATION
MODEL
NOMINAL VOLTAGE
RATED CAPACITY @ C20 AT 27OC (10.50 EBV)
IMEN (MM)
WEIGHT (KGS ± 5%)
Length (± 5mm)
Width (± 5mm)
Height (± 5mm)
LSB 42-12
12
42
198
167
175
13.5
LSB 65-12
12
65
350
167
190
22
LSB 80-12
12
80
307
169
240
23
LSB 100-12
12
100
330
173
222
29
LSB 120-12
12
120
406
171
240
35
LSB 150-12
12
150
485
170
240
44
MAXPRO20012
12
200
522
240
220
60
Also Available in 75Ah & 90Ah
ELECTROLYTE
Immobilized H2 So4
POSITIVE PLATE ALLOY
Arsenic and Cadmium Free Pb-Ca-Sn Alloy
POSITIVE PLATE TYPE
Flat Pasted
TYPE OF CONNECTION
Bolted
TYPE OF SEPARATOR MATERIAL
Absorptive Glass Mat
CONTAINER MATERIA
ABS
RECOMMENDED CHARGING METHOD
Constant Potential
SHELF LIFE AT 27 C
6 Months
SELF DISCHARGE
<1% per="per" week="week">1%>
FLOAT CHARGE VOLTAGE
13.5V - 13.62V
BOOST CHARGE VOLTAGE
13.8V - 14.1V
CHARGING TIME FROM 20% SOC TO 90% SOC
6-8 Hrs
OPERATING TEMPERATURE RANGE
"0OC to 50OC"
DESIGN LIFE AT 27 C
10 Years
CYCLIC SERVICE LIFE (@27 C)
AT 20% D.O.D
1400 Cycles
AT 50% D.O.D
650 Cycles
AT 80% D.O.D
300 Cycles
PRODUCT PERFORMANCE CONFORMS TO
JIS C 8702
APPLICATION
UPS System, Telecommunication Equipment, Fire Alarm & Security System, Office Automation, EP ABX, Banking & Financial Market, Data Center, Street Light, Electronic Weighing Scale and in many other applications.
